Emspira 3 Digital Microscope for Inspection
The Emspira 3 digital microscope is a cutting-edge tool tailored for precision inspection tasks. With advanced digital capabilities and high-quality imaging, this microscope transforms the inspection process, providing detailed and clear visualizations. Its user-friendly design and versatility make it an ideal choice for professionals seeking efficiency and accuracy in inspection applications. Elevate your inspection workflow with the Emspira 3, a digital microscope designed to meet the demands of meticulous inspection tasks with exceptional clarity and ease.
Loading...
Get free shippingIn the US
Online ordersNow available
Key Benefits
- Your integrated solution for comparison, measurement, and data sharing, allowing you to optimize inspection efficiency and ditch the PC
- Work the way you want. Adapt the solution to your requirements and the needs of individual users
- Focus confidently and reliably on your inspection work both in production and laboratory environments thanks to the robust design of Emspira 3
Components
Emspira 3 Digital Microscope for Inspection includes: |
Quantity |
|
|---|---|---|
 |
Emspira 310450851 |
1 |
|
Power cable, 2 m, USA10445661 |
1 |
|
WiFi Dongle 2.4/5GHz (US)12730524 |
1 |
|
1D Barcodescanner10450961 |
1 |
|
Focus drive 500 mm M-Series Routine10450172 |
1 |
|
Intermediate adapter for TL and IL Base10450434 |
1 |
|
Microscope carrier10450173 |
1 |
|
Inc. light base, large w. AntiShock feet10450049 |
1 |
|
Leica LED3000 RL, 58 mm10450271 |
1 |
|
Polarisation set for LED3000 RL10450337 |
1 |
|
Dust cover antistatic, small10447039 |
1 |
|
Objective 1.0x Planapo Z-series10447176 |
1 |
|
Adapter-Telecentric, 0.8x & 1.0x Planapo10450651 |
1 |
|
Standalone kit for Emspira 310450860 |
1 |
|
HP E27k G5 27" UHD11533663 |
1 |
Specifications:
- 4k 60fps live image via HDMI
- Antimicrobial PC/ABS housing with AgTreat™
- 8:1 zoom ratio with 26x- 206x magnification range (1x Planapo objective, optional 28"-monitor) & parfocal optics – from overview to detail
- Possible magnification range 8.2x to 1027x (depending on objective with 28" monitor)
- Coded zoom with click stop option for reproducible workflows
- JPG/TIFF/BMP images with up to 12 MP
- Full HD MJPG Video recording with 30 fps
- USB 3.1 type C connection
- control via Enersight Mobile (iOS/Android) or via Enersight OSD
- Including: USB C to A cable
- HP E27k G5 27" UHD
Features:
- Stand alone operation
- Control via mouse, keyboard, foot/hand switch and/or touchscreen
- Integrated measurement, annotation and sharing functionality
- Create overlays and reference images for comparison
- Capture directly to USB stick or network folder
- Send images via E-Mail
- Customizable UI for simplified workflows
