EZ4 E Stereo Microscope for Education with Integrated Wired Camera
The EZ4 E stereo microscope is a powerful tool for educational exploration, featuring outstanding optics and a user-friendly design. With its integrated wired camera, this microscope provides a seamless and efficient way for students to capture and document their discoveries. The wired camera ensures a reliable and stable connection, allowing students to easily share their observations and enhance their learning experience. The EZ4 E is the perfect choice for classrooms, enabling students to explore the microscopic world while effortlessly documenting their findings with the integrated wired camera.
Key Benefits
- Leica EZ4 E with integrated high definition digital camera and free LAS (Leica Application Software)
- The EZ4 E exclusively uses your facilities' network (WLAN or LAN) to allow users to connect to the microscope. This is an ideal solution if you don't want to add additional Wi-Fi access points to your network
- Ideal for learning and performing quality control and routine laboratory techniques
- Features high-quality image, color, and detail fidelity
Components
EZ4 E Stereo Microscope for Education with Integrated Wired Camera includes: |
Quantity |
|
|---|---|---|
 |
Leica EZ4 E Stereomicroscope10450811 |
1 |
|
IR Remote Control RC310450805 |
1 |
Specifications:
- 10x eyepieces
- 4.4:1 Zoom Stereo Microscope with built in 5 MPixel HD digital camera and 8x-35x zoom range
- 10x/20 mm high eyepoint
- Non-removable eyepieces
- exclusive 50-75 mm Interpupillary distance
- 100 mm working distance
- Student proof
- All-in-one plug and play design
- No removable parts
- Tool-free tension control
- Built-in 25,000 hour 6500 K Reflected, 4500 K Transmitted, true daylight, constant-color temperature power LED illumination for BOTH reflected and transmitted light, variable light intensity control for reflected and transmitted light.
- Reflected light transmitted light can and be used separately or simultaneously
- exclusive 3 directional reflected illumination (fill, top and oblique)
- Power switch located on back of stand
- exclusive auto-shutoff after 120 minutes
- Sealed stage plate
- Sealed light control panel on rear of stage area
- Built in SD card slot
- Built-in universal voltage stabilizing power supply accommodates 100-240 V input, fully safety rated.
Camera functions:
- HD Mode for Live image 1920x1080p directly to an HD display or for image capture to SD card (No PC required)
- PC mode for use with PC and Imaging Software
- Network mode for direct connection using Ethernet cable
- Camera is integrated into the microscope stand
- Light distribution: 50% visual / 50% camera
- Interfaces: USB2, HDMI, Ethernet
- Maximum Image size 5.0 Mpixel (2592 x 1944)
- Complete kit contains Microscope, USB2 cable 1.8m, HDMI cable 2.5m,imaging software for basic image capture and simple measuring and annotation applications, Quck start guide, Safety Booklet, Dust Cover, Country Specific Power Cord. Software LAS EZ.
EZ4 Educational stereo microscope for beginners in college and university
Stereo microscope for beginners in college and university education with 8x to 35x magnification and 7-way LED illumination
